2/19/25 1438Z | 2/19/27 1438Z | | !FDC 5/4204 5M0 PART 1 OF 2 ODP HARTSELLE/MORGAN COUNTY RGNL,
HARTSELLE, AL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 18: TREE, POLE, BUILDING, TRAVERSE WAY
BEGINNING 41 FT FROM DER, 228 FT LEFT OF CENTERLINE, UP TO 101 FT
AGL/701 FT MSL. TREE 290 FT FROM DER, 299 FT RIGHT OF CENTERLINE,
110 FT AGL/690 FT MSL. TREES BEGINNING 643 FT FROM DER, 314 FT
RIGHT OF CENTERLINE, UP TO 121 FT AGL/700 FT MSL. TREE 800 FT FROM
DER, 391 FT LEFT OF CENTERLINE, 92 FT AGL/703 FT MSL. TREES
BEGINNING 1446 FT FROM DER, 9 FT LEFT OF CENTERLINE, UP TO 135 FT
AGL/708 FT MSL. TREES BEGINNING 1543 FT FROM DER, 44 FT RIGHT OF
CENTERLINE, UP TO 130 FT AGL/706 FT MSL. RWY 36: TREES BEGINNING 29
FT FROM DER, 240 FT LEFT OF CENTERLINE, UP TO 101 FT AGL/704 FT
MSL. FENCE 76 FT FROM DER, 291 FT RIGHT OF CENTERLINE, 19 FT
AGL/634 FT MSL.TREES BEGINNING 210 FT FROM DER, 209 FT LEFT OF
CENTERLINE, UP TO 101 FT AGL/706 FT MSL.TREE 244 FT FROM DER, 300
FT RIGHT OF CENTERLINE, 59 FT AGL/674 FT MSL. TREE, POLE BEGINNING
453 FT FROM DER, 7 FT LEFT OF CENTERLINE, UP TO 101 FT AGL/725 FT
MSL. TREE, POLE BEGINNING 562 FT FROM DER, 378 FT RIGHT OF
CENTERLINE, UP TO 93 FT AGL/697 FT MSL. TREE, POLE BEGINNING 773 FT
FROM DER, 27 FT RIGHT OF CENTERLINE, UP TO 99 FT AGL/711 FT MSL.
TREE, POLE BEGINNING 1591 FT FROM DER, 34 FT RIGHT OF CENTERLINE,
ALL OTHER DATA REMAINS AS PUBLISHED. 2502191438-2702191438EST
END PART 1 OF 2
!FDC 5/4204 5M0 PART 2 OF 2 ODP HARTSELLE/MORGAN COUNTY RGNL,
HARTSELLE, AL.
UP TO 93 FT AGL/716 FT MSL. TREE, POLE BEGINNING 1757 FT FROM DER,
17 FT RIGHT OF CENTERLINE, UP TO 87 FT AGL/727 FT MSL. TREE 2205 FT
FROM DER, 217 FT LEFT OF CENTERLINE, 102 FT AGL/727 FT MSL. TREES
BEGINNING 2602 FT FROM DER, 280 FT LEFT OF CENTERLINE, UP TO 72 FT
AGL/728 FT MSL. TREES BEGINNING 2629 FT FROM DER, 275 FT RIGHT OF
CENTERLINE, UP TO 100 FT AGL/746 FT MSL. TREE 3823 FT FROM DER, 879
FT LEFT OF CENTERLINE, 93 FT AGL/749 FT MSL. POLE 4884 FT FROM DER,
468 FT RIGHT OF CENTERLINE, 146 FT AGL/754 FT MSL.
POLE BEGINNING 4934 FT FROM DER, 384 FT LEFT OF CENTERLINE, UP TO
114 FT AGL/765 FT MSL. TOWER 1.8 NM FROM DER, 2954 FT LEFT OF
CENTERLINE, 249 FT AGL/928 FT MSL. ANTENNA, TOWER 2.1 NM FROM DER,
260 FT LEFT OF CENTERLINE, 305 FT AGL/992 FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2502191438-2702191438EST
END PART 2 OF 2
|
