| Domestic |
|
5/19/251400Z
|
!DEN 05/428 4V1 TWY A2 CLSD 2505191400-2506060600
|
|
5/19/250600Z
|
!DEN 05/429 4V1 AD AP ALL SFC WIP CONST 2505190600-2506100600
|
|
4/10/250000Z
|
!DEN 04/271 4V1 OBST TOWER LGT (ASR 1038600) 373832.20N1044611.50W (3.3NM SSE 4V1) 6762.1FT (397.0FT AGL) U/S 2504100000-2507080400
|
|
4/3/252359Z
|
!DEN 04/075 4V1 RWY 27 PAPI U/S 2504032359-2510032111EST
|
|
12/12/240621Z
|
!DEN 12/202 4V1 OBST TOWER LGT (ASR 1250619) 374720.00N1042913.90W (15.2NM ENE 4V1) 6923.9FT (804.1FT AGL) U/S 2412120621-2512312359
|
| FDC |
|
5/15/251725Z
|
!FDC 5/1543 4V1 PART 1 OF 2 ODP SPANISH PEAKS AIRFIELD,
WALSENBURG, CO.
GOSIP ONE DEPARTURE (RNAV) ...
TAKEOFF OBSTACLE NOTES:
RWY 9, FENCE 4 FT FROM DER, 419 FT LEFT OF CENTERLINE, 8 FT
AGL/6020 FT MSL.
TREE 14 FT FROM DER, 209 FT RIGHT OF CENTERLINE, 6020 FT MSL.
FENCE 67 FT FROM DER, 186 FT LEFT OF CENTERLINE, 8 FT AGL/6022 FT
MSL.
RWY 27, TERRAIN 3 FT FROM DER, 396 FT RIGHT OF CENTERLINE, 6049 FT
MSL.
TERRAIN 6 FT FROM DER, 453 FT LEFT OF CENTERLINE, 6053 FT MSL.
FENCE, TERRAIN BEGINNING 9 FT FROM DER, 418 FT RIGHT OF CENTERLINE,
UP TO 6 FT AGL/6057 FT MSL.
BUILDING 166 FT FROM DER, 465 FT LEFT OF CENTERLINE, 24 FT AGL/6073
FT MSL.
BUILDINGS, TRAVERSE WAY, POLES, TRANSMISSION LINES BEGINNING 179 FT
FROM DER, 360 FT LEFT OF CENTERLINE, UP TO 33 FT AGL/6083 FT MSL.
TRANSMISSION LINE, FENCE, TRAVERSE WAY, POLES BEGINNING 291 FT FROM
DER, 122 FT LEFT OF CENTERLINE, UP TO 32 FT AGL/6084 FT MSL.
TANK 333 FT FROM DER, 521 FT RIGHT OF CENTERLINE, 14 FT AGL/6066 FT
MSL.
2505151725-2705171725EST
END PART 1 OF 2
!FDC 5/1543 4V1 PART 2 OF 2 ODP SPANISH PEAKS AIRFIELD,
WALSENBURG, CO.
TRANSMISSION LINE, POLE, BUILDINGS, TOWER, TREE BEGINNING 387 FT
FROM DER, 307 FT RIGHT OF CENTERLINE, UP TO 22 FT AGL/6068 FT MSL.
POLE 1707 FT FROM DER, 432 FT LEFT OF CENTERLINE, 37 FT AGL/6092 FT
MSL.
TRANSMISSION LINE 5935 FT FROM DER, 1303 FT LEFT OF CENTERLINE, 56
FT AGL/6197 FT MSL.
POLE, TRANSMISSION LINE BEGINNING 1.7 NM FROM DER, 853 FT RIGHT OF
CENTERLINE, UP TO 6323 FT MSL.
POLE, TRANSMISSION LINE, ELECTRICAL SYSTEM BEGINNING 1.8 NM FROM
DER, 1027 FT RIGHT OF CENTERLINE, UP TO 63 FT AGL/6339 FT MSL.
TREES BEGINNING 2.3 NM FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 13
FT AGL/6442 FT MSL.
TREES BEGINNING 2.4 NM FROM DER, 24 FT RIGHT OF CENTERLINE, UP TO
11 FT AGL/6439 FT MSL.
TREES, TRAVERSE WAY BEGINNING 2.5 NM FROM DER, 5 FT RIGHT OF
CENTERLINE, UP TO 23 FT AGL/6457 FT MSL.
TRAVERSE WAY 2.5 NM FROM DER, 67 FT LEFT OF CENTERLINE, 6454 FT
MSL.
2505151725-2705171725EST
END PART 2 OF 2
|
|
12/10/242252Z
|
!FDC 4/4605 4V1 IAP SPANISH PEAKS AIRFIELD, WALSENBURG, CO.
RNAV (GPS) RWY 9, AMDT 1A...
LNAV CAT A/B/C MDA 6940/HAT 893, VIS CAT A 1 1/4. CIRCLING CAT A/B MDA 6940/HAA 885. TOWER ANTENNA 6632 MSL 2.8NM W OF RWY 9 (2024-ANM-6724-OE PERMANENT).
2412102252-2612102252EST
|
