| Domestic |
|
3/28/250755Z
|
!OLU 03/188 4D9 OBST TOWER LGT (ASR 1031256) 400703.00N0991736.30W (2.5NM E 4D9) 2373.0FT (288.1FT AGL) U/S 2503280755-2507042359
|
| FDC |
|
1/14/251505Z
|
!FDC 5/3189 4D9 IAP ALMA MUNI, ALMA, NE.
RNAV (GPS) RWY 35, ORIG...
LNAV CAT A/B MDA 2840/HAT 768. VIS CAT B 1 1/4.
CIRCLING CAT A/B MDA 2840/HAA 767. VIS CAT B 1 1/4.
DISREGARD HUSTO FIX AND HUSTO FIX ALTITUDE.
TOWER, 2412 MSL, 3.69 NM SOUTH OF RWY 35 (2024-ACE-6726-OE).
2501141505-2701141505EST
|
|
4/23/241710Z
|
!FDC 4/4166 4D9 PART 1 OF 2 ODP ALMA MUNI, ALMA, NE.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 17, LIGHT POLE 9 FT FROM DER, 10 FT
LEFT OF CENTERLINE, 2 FT AGL/2064 FT MSL.
LIGHT POLES 10 FT FROM DER, 10 FT RIGHT OF CENTERLINE, 2 FT
AGL/2064 FT MSL.
TREE 417 FT FROM DER, 489 FT RIGHT OF CENTERLINE, 34 FT AGL/2085 FT
MSL.
TREES BEGINNING 435 FT FROM DER, 459 FT RIGHT OF CENTERLINE, UP TO
37 FT AGL/2088 FT MSL.
POLES BEGINNING 734 FT FROM DER, 318 FT RIGHT OF CENTERLINE, UP TO
42 FT AGL/2089 FT MSL.
RWY 35, TRAVERSE WAY 50 FT FROM DER, 163 FT RIGHT OF CENTERLINE,
2081 FT MSL.
TERRAIN 58 FT FROM DER, 403 FT LEFT OF CENTERLINE, 2078 FT MSL.
TERRAIN 128 FT FROM DER, 476 FT LEFT OF CENTERLINE, 2079 FT MSL.
TRAVERSE WAY 162 FT FROM DER, 164 FT RIGHT OF CENTERLINE, 2082 FT
MSL.
TRAVERSE WAY 413 FT FROM DER, 598 FT LEFT OF CENTERLINE, 2095 FT
MSL.
POLE, TRAVERSE WAYS BEGINNING 523 FT FROM DER, 249 FT LEFT OF
2404231710-2604231710EST
END PART 1 OF 2
!FDC 4/4166 4D9 PART 2 OF 2 ODP ALMA MUNI, ALMA, NE.
CENTERLINE, UP TO 2104 FT MSL.
POLES, TRAVERSE WAY, AGRICULTURAL EQUIPMENT BEGINNING 612 FT FROM
DER, 458 FT LEFT OF CENTERLINE, UP TO 34 FT AGL/2114 FT MSL.
TREES, POLES BEGINNING 855 FT FROM DER, 546 FT LEFT OF CENTERLINE,
UP TO 2119 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2404231710-2604231710EST
END PART 2 OF 2
|
