CAMP LAKE - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

49C
Local 49C
CAMP LAKE
PublicPUB

1 miles W of CAMP LAKE, WI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
42° 31' 40"N 88° 09' 22"W
Elevation
749' MSL
Pattern Alt
1349' MSL
Mag Variation
4°W
Declination
1°W
Fuel
None Listed
FSS
GREEN BAY (GRB)
Sectional
CHICAGO
ARTCC
CHICAGO (ZAU)
Data Effective
2/19/26-3/19/26
KENW (10nm) LIFR
8:53 PM CST
Mist
Overcast 300'
0.5sm
39°F
37°F
30.04"Hg
060° 5kts
METAR KENW 050253Z 06005KT 1/2SM BR OVC003 04/03 A3004
+ Add Your Business

49C FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KENW (10nm)
Wed, 3/4 7:54 PM CST
Wed, 3/4 8:00 PM CST - Thu, 3/5 6:00 PM CST
LIFR
8:00 PM CST - 3:00 AM CST
Mist
Overcast 400'
1sm
VRB° 4kts
LIFR
3:00 AM CST - 8:00 AM CST
Mist
Overcast 300'
1sm
VRB° 4kts
LIFR
4:00 AM CST - 8:00 AM CST
Light Rain and Mist
Overcast 100'
0.75sm
Calm
LIFR
8:00 AM CST - 10:00 AM CST
Fog
Overcast 200'
0.5sm
050° 6kts
LIFR
8:00 AM CST - 10:00 AM CST
Light Rain
Overcast 100'
0.5sm
Calm
LIFR
10:00 AM CST - 1:00 PM CST
Light Rain and Mist
Overcast 100'
0.75sm
Calm
LIFR
10:00 AM CST - 6:00 PM CST
Mist
Overcast 300'
1sm
050° 7kts
TAF KENW 050154Z 0502/0524 VRB04KT 1SM BR OVC004
   FM050900 VRB04KT 1SM BR OVC003
   PROB30 0510/0514 3/4SM -RA BR OVC001
   FM051400 05006KT 1/2SM FG OVC002
   PROB30 0514/0516 1/2SM -RA OVC001
   FM051600 05007KT 1SM BR OVC003
   PROB30 0516/0519 3/4SM -RA BR OVC001
49C
EffectiveExpiresCategoryNOTAM
Domestic
2/14/26
1811Z
4/14/26
1811Z
!GRB 02/352 49C OBST TOWER LGT (ASR 1050567) 423445.00N0881319.00W (4.2NM NW 49C) 1016.7FT (194.9FT AGL) U/S 2602141811-2604141811
No
UNATTND
CAMP LAKE AIRPORT LLC
28701 98TH ST
SALEM, WI 53168
Phone: 847-612-8552
ELLIOTT EIDEN
28701 98TH ST
SALEM, WI 53168
Phone: 847-612-8552
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
GRB
--
--
N/A
Yes
No
No
Tie-Down
No
Major
Major
None
None
None

Runway 18/36

2210 ft. x 75 ft.
TURF
Good
NONE


--
--
--
--
  Runway 18 Runway 36
True Heading 180°0°
Traffic Pattern Left
Markings
Markings Condition
Latitude 42° 31' 51"N 42° 31' 29"N
Longitude 88° 09' 22"W 88° 09' 22"W
Elevation 749' 747'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT NOT PLWD; CFM CONDS WITH AMGR.
A110-3DEER & BIRDS ON AND INVOF ARPT.
A110-4FOR CD CTC CHICAGO ARTCC AT 630-906-8921.
A16ELLIOTTEIDEN3@GMAIL.COM.
A42-18_MARKMKD WITH ORANGE/WHITE A-FRAMES.
A42-36_MARKMKD WITH ORANGE/WHITE A-FRAMES.
A57-18CTLG OBST EXCEEDS 45 DEG SLP.
A57-36CTLG OBST EXCEEDS 45 DEG SLP.
E111PRVDD THR DSPLCD SO AS TO PRVD A MINIMUM OF 20-1 CLNC OVER ALL OBSTNS IN APCH AREA; ALL TFC PAT OPNS CONDUCTED ON THE E SIDE OF N/S RWY.
CAMP LAKE (IATA: 49C) is a public airport located in CAMP LAKE, WI, US.
