!FDC 3/0497 48I PART 1 OF 4 ODP BRAXTON COUNTY, SUTTON, WV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 2: TREE, FENCE BEGINNING 22 FT FROM
DER, 248 FT
LEFT OF CENTERLINE, UP TO 1351 FT MSL. TREE, TERRAIN BEGINNING 56
FT FROM DER, 239 FT RIGHT OF
CENTERLINE, UP TO 1352 FT MSL. TREES, FENCE, TRAVERSE WAYS, POLE
BEGINNING 90 FT FROM DER, 90 FT
RIGHT OF CENTERLINE, UP TO 1402 FT MSL. TREE 94 FT FROM DER, 451 FT
LEFT OF CENTERLINE, 1416 FT MSL.
TREES, FENCES, TRAVERSE WAYS, TERRAINS BEGINNING 138 FT FROM DER,
48 FT LEFT OF CENTERLINE, UP TO
1417 FT MSL. TREES, TERRAINS BEGINNING 775 FT FROM DER, 259 FT
RIGHT OF CENTERLINE, UP TO 1409 FT
MSL. TREE 913 FT FROM DER, 650 FT LEFT OF CENTERLINE, 1421 FT MSL.
TREES BEGINNING 1000 FT FROM DER,
425 FT LEFT OF CENTERLINE, UP TO 1426 FT MSL. TREE 1083 FT FROM
DER, 533 FT LEFT OF CENTERLINE, 1433
FT MSL. TREE 1084 FT FROM DER, 336 FT LEFT OF CENTERLINE, 1434 FT
MSL. TREES BEGINNING 1107 FT FROM
DER, 234 FT LEFT OF CENTERLINE, UP TO 1435 FT MSL. TREES BEGINNING
FT LEFT OF CENTERLINE, UP TO 1529 FT MSL. 2306141521-2506141521EST
END PART 1 OF 4
!FDC 3/0497 48I PART 2 OF 4 ODP BRAXTON COUNTY, SUTTON, WV.
1141 FT FROM DER, 440 FT LEFT OF
CENTERLINE, UP TO 1438 FT MSL. TREE 1199 FT FROM DER, 540 FT LEFT
OF CENTERLINE, 1441 FT MSL. TREES,
POLES, BUILDING BEGINNING 1201 FT FROM DER, 9 FT LEFT OF
CENTERLINE, UP TO 1445 FT MSL. TREES
BEGINNING 1288 FT FROM DER, 11 FT RIGHT OF CENTERLINE, UP TO 1435
FT MSL. TREES, POLE BEGINNING 4237
FT FROM DER, 498 FT LEFT OF CENTERLINE, UP TO 1471 FT MSL. TREES
BEGINNING 4341 FT FROM DER, 623 FT
LEFT OF CENTERLINE, UP TO 1475 FT MSL. TREES, TERRAIN BEGINNING
4508 FT FROM DER, 409 FT LEFT OF
CENTERLINE, UP TO 1484 FT MSL. RWY 20: TREES BEGINNING 26 FT FROM
DER, 311 FT RIGHT OF CENTERLINE,
UP TO 1312 FT MSL. TERRAIN 71 FT FROM DER, 363 FT LEFT OF
CENTERLINE, 1297 FT MSL. TREES BEGINNING 90
FT FROM DER, 263 FT LEFT OF CENTERLINE, UP TO 1432 FT MSL. TREES,
FENCE, TRAVERSE WAY, POLE
BEGINNING 187 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO 1435 FT
MSL. TREE 215 FT FROM DER, 349 FT
RIGHT OF CENTERLINE, 1328 FT MSL. TREES BEGINNING 269 FT FROM DER,
FT LEFT OF CENTERLINE, UP TO 1529 FT MSL. 2306141521-2506141521EST
END PART 2 OF 4
!FDC 3/0497 48I PART 3 OF 4 ODP BRAXTON COUNTY, SUTTON, WV.
ON AND RIGHT OF CENTERLINE, UP
TO 1338 FT MSL. TREE 622 FT FROM DER, 396 FT RIGHT OF CENTERLINE,
1344 FT MSL. TREE 629 FT FROM DER,
667 FT RIGHT OF CENTERLINE, 1370 FT MSL. TREES BEGINNING 634 FT
FROM DER, 17 FT RIGHT OF CENTERLINE,
UP TO 1376 FT MSL. TREE 1773 FT FROM DER, 975 FT RIGHT OF
CENTERLINE, 1385 FT MSL. TREES BEGINNING
1798 FT FROM DER, 179 FT RIGHT OF CENTERLINE, UP TO 1401 FT MSL.
TREES BEGINNING 1869 FT FROM DER,
460 FT RIGHT OF CENTERLINE, UP TO 1406 FT MSL. TREES BEGINNING 1947
FT FROM DER, 230 FT RIGHT OF
CENTERLINE, UP TO 1434 FT MSL. TREES BEGINNING 1992 FT FROM DER,
225 FT RIGHT OF CENTERLINE, UP TO
1447 FT MSL. TREES BEGINNING 2170 FT FROM DER, 224 FT RIGHT OF
CENTERLINE, UP TO 1464 FT MSL. TREES
BEGINNING 2196 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO 1440 FT
MSL. TREES BEGINNING 2303 FT
FROM DER, 44 FT RIGHT OF CENTERLINE, UP TO 1485 FT MSL. TREES
BEGINNING 3095 FT FROM DER, 118 FT
RIGHT OF CENTERLINE, UP TO 1499 FT MSL. TREES BEGINNING 3155 FT
FT LEFT OF CENTERLINE, UP TO 1529 FT MSL. 2306141521-2506141521EST
END PART 3 OF 4
!FDC 3/0497 48I PART 4 OF 4 ODP BRAXTON COUNTY, SUTTON, WV.
FROM DER, 332 FT RIGHT OF
CENTERLINE, UP TO 1513 FT MSL. TREES BEGINNING 3196 FT FROM DER, 3
FT RIGHT OF CENTERLINE, UP TO
1515 FT MSL. TREES BEGINNING 4415 FT FROM DER, 907 FT LEFT OF
CENTERLINE, UP TO 1442 FT MSL. TREES
BEGINNING 4443 FT FROM DER, 797 FT LEFT OF CENTERLINE, UP TO 1461
FT MSL. TREES BEGINNING 4520 FT
FROM DER, 986 FT LEFT OF CENTERLINE, UP TO 1477 FT MSL. TREES
BEGINNING 4546 FT FROM DER, 522 FT
LEFT OF CENTERLINE, UP TO 1482 FT MSL. TREES BEGINNING 4638 FT FROM
DER, 431 FT LEFT OF CENTERLINE,
UP TO 1495 FT MSL. TREES BEGINNING 4958 FT FROM DER, 597 FT LEFT OF
CENTERLINE, UP TO 1507 FT MSL.
TREES BEGINNING 5041 FT FROM DER, 500 FT LEFT OF CENTERLINE, UP TO
1508 FT MSL. TREES BEGINNING
5067 FT FROM DER, 311 FT LEFT OF CENTERLINE, UP TO 1528 FT MSL.
TREES BEGINNING 5574 FT FROM DER, 98
FT LEFT OF CENTERLINE, UP TO 1529 FT MSL. 2306141521-2506141521EST
