MINA - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

3Q0
Local 3Q0
MINA
PublicPUB

0 miles SE of MINA, NV, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
38° 22' 47"N 118° 05' 48"W
Elevation
4557' MSL
Pattern Alt
5557' MSL
Mag Variation
12°E
Declination
15°E
Fuel
None Listed
FSS
RENO (RNO)
Sectional
SAN FRANCISCO
ARTCC
OAKLAND (ZOA)
Data Effective
2/19/26-3/19/26
KHTH (27nm) VFR
7:55 PM PST
Clear
10sm
48°F
25°F
30.11"Hg
170° 5kts
A01
METAR KHTH 040355Z AUTO 17005KT 10SM CLR 09/M04 A3011 RMK A01
+ Add Your Business

3Q0 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KTPH (51nm)
Tue, 3/3 3:20 PM PST
Tue, 3/3 4:00 PM PST - Wed, 3/4 4:00 PM PST
VFR
4:00 PM PST - 8:00 PM PST
Sky Clear
6sm
220° 5kts
VFR
8:00 PM PST - 8:00 AM PST
Sky Clear
6sm
010° 8kts
VFR
8:00 AM PST - 12:00 PM PST
Broken 20,000'
6sm
180° 5kts
VFR
12:00 PM PST - 4:00 PM PST
Broken 20,000'
6sm
230° 15kts
Gusts 25kts
TAF KTPH 032320Z 0400/0424 22005KT P6SM SKC
   FM040400 01008KT P6SM SKC
   FM041600 18005KT P6SM BKN200
   FM042000 23015G25KT P6SM BKN200
3Q0
No NOTAM Available
No
UNATNDD
U S BLM
P.O. BOX 12000
RENO, NV 89520
Phone: 775-861-6400
CHARLES FROST
BOX 407
MINA, NV 89422
Phone: 775-573-2214
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
RNO
--
--
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
None

Runway 13/31

4600 ft. x 165 ft.
DIRT
Good
NONE


--
--
--
--
  Runway 13 Runway 31
True Heading 152°332°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 38° 23' 08"N 38° 22' 27"N
Longitude 118° 06' 02"W 118° 05' 35"W
Elevation 4,542' 4,557'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-2RY 13/31 HAS 2 FT BERMS ON BOTH SIDES FULL LENGTH OF RY.
A110-3RY 13/31 HAS UNCONTROLLED VEHICLE ACCESS.
A110-4ULTRALIGHTS ON & INVOF ARPT.
A110-5REMOTE CONTROLLED AIRCRAFT INVOF ARPT.
A110-6WILD HORSES, BURROS, AND BIG HORN SHEEP IN AIRPORT ENVIRONMENT
A110-7TWY TO OFF RWY PRKG AREA BLOCKED BY 3 FT HIGH CATTLE GUARD RAILS THAT COULD DAMAGE LOW WING ACFT.
A110-8FOR CD CTC OAKLAND ARTCC AT 510-745-3380.
A42-13_MARK13/31 THLDS MARKED WITH WHITE TIRES.
E111ESTABD PRIOR TO 5/15/59.
MINA (IATA: 3Q0) is a public airport located in MINA, NV, US.
