3K3
SYRACUSE-HAMILTON COUNTY MUNI
PublicPUB

1 miles N of SYRACUSE, KS
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 59' 55"N 101° 44' 51"W
3326' MSL
4326' MSL
07E
100LL
WICHITA (ICT)
WICHITA
DENVER (ZDV)
7/11/24-8/8/24
K3K3 VFR
4:35 AM MDT
No Clouds
10sm
50°F
41°F
29.84"Hg
270° 6kts
AO2
K3K3 191035Z AUTO 27006KT 10SM 10/05 A2984 RMK AO2
Add Your Business

3K3 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3

AWOS-3
620-384-5869
 119.975

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KGCK (49nm)
Thu, 9/19 12:20 AM CDT
Thu, 9/19 1:00 AM CDT - Fri, 9/20 1:00 AM CDT
VFR
1:00 AM CDT - 6:00 AM CDT
Sky Clear
6sm
160° 9kts
VFR
6:00 AM CDT - 8:00 AM CDT
Sky Clear
6sm
220° 10kts
VFR
8:00 AM CDT - 9:00 AM CDT
Sky Clear
6sm
260° 10kts
VFR
9:00 AM CDT - 11:00 AM CDT
Sky Clear
6sm
310° 11kts
Gusts 18kts
VFR
11:00 AM CDT - 7:00 PM CDT
Sky Clear
6sm
350° 11kts
Gusts 18kts
VFR
7:00 PM CDT - 1:00 AM CDT
Sky Clear
6sm
030° 6kts
KGCK 190520Z 1906/2006 16009KT P6SM SKC
   FM191100 22010KT P6SM SKC
   FM191300 26010KT P6SM SKC
   FM191400 31011G18KT P6SM SKC
   FM191600 35011G18KT P6SM SKC
   FM200000 03006KT P6SM SKC
3K3
Domestic
9/6/240540Z !ICT 09/065 3K3 OBST TOWER LGT (ASR 1325070) 375311.40N1014230.60W (6.96NM SSE 3K3) 3773FT (435FT AGL) U/S 2409060540-2410211711
FDC
9/16/241617Z !FDC 4/6196 3K3 ODP SYRACUSE-HAMILTON COUNTY MUNI, SYRACUSE, KS.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 18, BUILDING, 423FT FROM DER, 520FT RIGHT OF CENTERLINE, 28 AGL/3342 MSL (2024-ACE-4608-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2409161617-2609161617EST
No
MON-FRI 0800-1700
FOR ATTENDANT AFT HRS CALL 620-384-5835
CITY OF SYRACUSE/HAMILTON CO
BOX 1136
SYRACUSE, KS 67878
Phone: 620-384-5629
STEVE PHILLIPS
BOX 1136
SYRACUSE, KS 67878
Phone: 620-384-5468
WICHITA FSS (ICT)
Toll Free: 1-800-WX-BRIEF
ICT
--
DUSK-DAWN. ACTVT MIRL RWY 13/31 & RWY 18/36; PAPI RWY 18 & 36 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
21
0
0
0
0
0
Minor
Minor
None
None
Crop Dusting

Runway 13/31

3000 ft. x 40 ft.
ASPH
Good
NONE
MED
5 /F/C/Y/U
--
--
--
--
  Runway 13 Runway 31
True Heading 135°315°
Traffic Pattern Left Right
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 37° 59' 48"N 37° 59' 27"N
Longitude 101° 45' 04"W 101° 44' 37"W
Elevation 3,312' 3,303'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 18/36

4600 ft. x 75 ft.
CONC
Good
NONE
MED
11 /R/C/X/U
30,000lbs
30,000lbs
--
--
  Runway 18 Runway 36
True Heading 190°10°
Traffic Pattern Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 00' 29"N 37° 59' 44"N
Longitude 101° 44' 47"W 101° 44' 57"W
Elevation 3,326' 3,315'
Threshold Crossing Height 35 ft. AGL 44 ft. AGL
Visual Glide Path Angle 3° 3.2°
Visual Slope Indicator P4R P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1PUBLIC PHONE 620-384-5835.
A110-2FOR CD CTC DENVER ARTCC AT 303-651-4257.
SYRACUSE-HAMILTON COUNTY MUNI (IATA: 3K3) is a public airport located in SYRACUSE, KS.
