TECUMSEH MILLS - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

22T
Local 22T
TECUMSEH MILLS
PublicPUB

4 miles NE of TECUMSEH, MI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
42° 02' 02"N 83° 52' 42"W
Elevation
797' MSL
Pattern Alt
1797' MSL
Mag Variation
7°W
Fuel
None Listed
FSS
LANSING (LAN)
Sectional
DETROIT
ARTCC
CLEVELAND (ZOB)
Data Effective
2/19/26-3/19/26
KARB (13nm) IFR
5:53 AM EST
Mist
Clear
2sm
23°F
23°F
30.24"Hg
Calm
AO2 SLP251 T10501050 $
METAR KARB 041053Z AUTO 00000KT 2SM BR CLR M05/M05 A3024 RMK AO2 SLP251 T10501050 $
+ Add Your Business

22T FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KYIP (20nm)
Wed, 3/4 12:28 AM EST
Wed, 3/4 1:00 AM EST - Thu, 3/5 1:00 AM EST
MVFR
1:00 AM EST - 3:00 AM EST
Mist
Scattered 25,000'
Scattered 1,500'
5sm
VRB° 3kts
IFR
3:00 AM EST - 5:00 AM EST
Mist
Scattered 25,000'
Scattered 400'
2sm
VRB° 2kts
LIFR
5:00 AM EST - 11:00 AM EST
Mist
Obscured
0.75sm
VRB° 2kts
MVFR
11:00 AM EST - 2:00 PM EST
Mist
Broken 1,000'
Scattered 500'
4sm
100° 5kts
VFR
2:00 PM EST - 8:00 PM EST
Broken 25,000'
6sm
120° 5kts
MVFR
8:00 PM EST - 1:00 AM EST
Light Drizzle and Mist
Overcast 1,000'
4sm
150° 5kts
TAF KYIP 040528Z 0406/0506 VRB03KT 5SM BR SCT015 SCT250
   FM040800 VRB02KT 2SM BR SCT004 SCT250
   FM041000 VRB02KT 3/4SM BR VV004
   FM041600 10005KT 4SM BR SCT005 BKN010
   FM041900 12005KT P6SM BKN250
   FM050100 15005KT 4SM -DZ BR OVC010
22T
No NOTAM Available
No
UNATNDD
DANIEL MILLS
9398 NEAL RD
MANCHESTER, MI 48158
Phone: 734-476-1517
DANIEL MILLS
9398 NEAL RD
MANCHESTER, MI 48158
Phone: 734-476-1517
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
LAN
--
--
N/A
Yes
No
No
Tie-Down
No
None
None
None
None
None

Runway 07/25

4258 ft. x 75 ft.
ASPH
Fair
NONE


--
--
--
--
  Runway 07 Runway 25
True Heading 63°243°
Traffic Pattern
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 42° 01' 54"N 42° 02' 14"N
Longitude 83° 53' 11"W 83° 52' 21"W
Elevation 794' 794'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 13/31

4278 ft. x 75 ft.
ASPH
Fair
NONE


--
--
--
--
  Runway 13 Runway 31
True Heading 125°305°
Traffic Pattern
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 42° 02' 12"N 42° 01' 48"N
Longitude 83° 53' 01"W 83° 52' 15"W
Elevation 789' 794'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1FOR CD CTC DETROIT APCH AT 734-955-1404.
A110-3DEER & LRG BIRDS ON & INVOF ARPT.
A110-5CALL AMGR TO VFY FLD CONDS IN WINTER MONTHS.
A57-07APCH RATIO 20:1 TO DTHR OVR +83 FT TREE, 1693 FT DIST, 20 FT L.
A57-13APCH RATIO 19:1 TO DTHR OVR +99 FT TREE, 1950 FT DIST, 0 FT B.
A57-25+27 FT UNMKD PLINE, 650-800 FT DIST; +55 FT MKD PLINE, 1500-1800 FT DIST.
A58-07+10 FT SEASONAL CROPS, 0 FT DIST, 125 FT L/R.
A58-25+10 FT PVT ROAD, 0 FT DIST, 95 FT R; +6 FT SEASONAL CROPS.
A58-31+3 FT FENCE ATOP +9 FT ELEVD TRRN, 145-200 FT DIST, 40-125 FT R.
E111PRVDD ANY OBSTNS REMOVED/LWRD OR THR DSPLCD & CLEARLY MKD TO PRVD A MNM 20:1 APCH SLP SFC CLNC OVR ANY OBSTNS IN THE RWY APCH; THE RWY OFZ IS TO BE FREE OF OBSTNS IN THAT AREA 125 FT EITHER SIDE OF THE RWY CNTRLN & EXTDG 200 FT OFF THE RWY ENDS; THE RWY SAFETY AREA IS TO BE FREE OF OBJECTS & POTENTIALLY HAZUS RUTS, HUMPS, DEPRESSIONS, ETC IN THAT AREA 60 FT EITHER SIDE OF THE RWY CNTRLN & EXTDG 240 FT OFF THE RWY ENDS.
TECUMSEH MILLS (IATA: 22T) is a public airport located in TECUMSEH, MI, US.
