No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

0A8
BIBB COUNTY
PublicPUB

3 miles E of CENTREVILLE, AL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 56' 13"N 87° 05' 26"W
251' MSL
1251' MSL
02W
None Listed
ANNISTON (ANB)
ATLANTA
ATLANTA (ZTL)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

0A8 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.975 122.975

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
0A8
Domestic
1/13/250513Z !ANB 01/308 0A8 OBST TOWER LGT (ASR 1277623) 325851.50N0865456.10W (9.3NM ENE 0A8) 940.0FT (415.0FT AGL) U/S 2501130513-2501280413
1/12/250720Z !ANB 01/297 0A8 OBST TOWER LGT (ASR 1037022) 330542.00N0871516.00W (12.5NM NW 0A8) 1443.9FT (934.1FT AGL) U/S 2501120720-2502260719
1/11/250557Z !ANB 01/270 0A8 OBST TOWER LGT (ASR 1250880) 324700.90N0865355.90W (13.2NM SE 0A8) 963.3FT (409.1FT AGL) U/S 2501110557-2501260457
1/4/252335Z !ANB 01/072 0A8 OBST TOWER LGT (ASR 1221009) 325017.10N0871506.10W (10.2NM SW 0A8) 600.7FT (346.8FT AGL) U/S 2501042335-2504040500
12/29/240530Z !ANB 12/674 0A8 OBST TOWER LGT (ASR 1277300) 324013.10N0870751.50W (16.1NM S 0A8) 922.9FT (424.9FT AGL) U/S 2412290530-2503290500
10/11/241252Z !ANB 10/246 0A8 RWY 10 RWY END ID LGT U/S 2410111252-2504142111EST
10/11/241251Z !ANB 10/245 0A8 RWY 28 RWY END ID LGT U/S 2410111251-2504142111EST
9/9/241215Z !ANB 09/244 0A8 RWY 10 PAPI U/S 2409091215-2503102111EST
FDC
9/19/231707Z !FDC 3/1990 0A8 ODP BIBB COUNTY, CENTREVILLE, AL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF MINIMUMS: RWY 10, 300-1 1/4 WITH MINIMUM CLIMB OF 204 FT/NM TO 900 OR STANDARD WITH MINIMUM CLIMB OF 341 FT/NM TO 600.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309191707-2509191707EST
No
UNATNDD
ARPT UNATNDD.
BIBB COUNTY COMMISSION
157 SW DAVIDSON DRIVE
CENTREVILLE, AL 35042
Phone: (205) 926-3114
SHANE WALLACE
P.O BOX 308
CENTREVILLE, AL 35042
Phone: 205-247-6001
ANNISTON FSS (ANB)
Toll Free: 1-800-WX-BRIEF
ANB
--
ACTVT REIL RWY 10 & 28; PAPI RWY 10 & 28; MIRL RWY 10/28 - CTAF.
N/A
Yes - Lighted
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
Minor
None
None
None

Runway 10/28

4206 ft. x 80 ft.
ASPH
Excellent
AFSC
MED

18,000lbs
--
--
--
  Runway 10 Runway 28
True Heading 95°275°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 32° 56' 15"N 32° 56' 11"N
Longitude 87° 05' 51"W 87° 05' 01"W
Elevation 238' 251'
Threshold Crossing Height 40 ft. AGL 40 ft. AGL
Visual Glide Path Angle 4° 4°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1PILOT ACES VIA WALK THRU GATE ON NORTH SIDE OF ARPT.
A110-2FOR CD CTC ATLANTA ARTCC AT 770-210-7692.
BIBB COUNTY (IATA: 0A8) is a public airport located in CENTREVILLE, AL.
